Yamaha Lithium Ion with charge-life indicator and self-diagnosis display

Side-exiting dock station with anti-vibration mounting plate

Weight 6.61lb

500Wh 36V

4-hour charge time

52.2 (S), 52.4 (M), 52.6 (L)

PWSeries ST3-bolt Mount
Square taper spindle
Quad Sensor System with rear hub speed sensor
Weight: 7.71lb
Rated power: 250W (Nominal), 500W (Max)
Max torque: 70Nm
Max cadence support: 110rpm
Max speed support: 28mph
Support modes: AUTO, ECO+, ECO, STANDARD, HIGH

Computer control functions include: (4) Power-level control switch, stop watch, distance units, power-level LED on/off, cycling function display items, time adjustment, LED headlamp power on/off, 3-color LED power assist level light indicator

Cycling function display include: speed, average speed, maximum speed, trip distance, odometer, cadence, battery capacity (%)

Yamaha Hydroformed Aluminum
Integrated batteryWater bottle boss
Tapered Headtube
Internal shift/brake hose routing
Rack/Fender compatible

SR Suntour NEX E25. 63mm Travel

2x100mm Thru-Axle

Integrate headset with 30mm headset spacers

Yamaha Alloy 4-bolt faceplate

31.8 Diameter

80mm Length (53cm, 55cm)

100mm Length (58cm)

Alloy flat bar zero degree rise
31.8mm Diameter
640mm Width

Two-Tone Ergonomic Locking

Alloy 30.9 x 295mm (S), 345mm (M L) with 2-bolt adjustable tilt saddle rail clamp

Alloy 2-Bolt 35.0mm

Yamaha Urban Comfort Cro-Mo Rail

MAXLE 15MM X 110MM BOOST THRU AXLE

Shimano M2010 9-Speed
Gear Selection Window

Front – Shimano Sora (2×9) Braze-On

Rear– Shimano M3100 SGS

Square Taper
165mm (S)
170mm (M, L)

KMC e11 118 links

SHIMANO HG400 9-Speed

11-13-15-17-20-23-26-30-36T

SAMOX 44t

SHIMANO MT200 Front/Rear

SHIMANO SM RT21, 180mm Front, 160mm Rear

275” 32-Hole Dual Channel Welded Pin w/ Eyeleted Spoke

SUS304 14G

Front – 12x100mm Quick-Release Thru-Axle (QRTA)

Rear – 12x142mm QRTA with Integrated Speed Sensor

CST C1996 27.5×2.0”

• Included Kickstand
• Yamaha Battery Changer
• Bell
• LED Headlight
