Key Information
BATTERY
Yamaha 500Wh with Charge-life indicator and Self-diagnosis display
Anti-Vibration Mounting Plate
Weight: 6.61 lbs
500Wh 36V
Re-charge time: 1-hour 80%, 4-hour 100%
Weight
51.1 lb (Medium)
MOTOR
YAMAHA PW-X3 Class 1 Labeled Centermount ISIS Splined
Crankarm Spindle YAMAHA Quad Sensor with Automatic Support and Walk Assist Modes
Rate power: 250W (nominal), 500W(maximum)
Max torque: 85Nm
Max speed support: 20MPH
Support Modes: ECO, Standard, High, MTB, Extra-Power, Automatic, Walk Assist
CONTROL SWITCH AND COMPUTER
YAMAHA Interface X Control functions include: 3-color LED support-mode level light indicator, (5) Support-mode control switch, plus AUTOMATIC support mode (Aqua LED indicator) and Walk Assist mode (Purple LED indicator), Bluetooth™ connectivity, 3-color LED support-mode level light indicator, LED brightness adjustability, battery capacity (4-LED capacity indicators)
FRAME
YAMAHA Dual Twin Frame
Tapered Headtube
Internal cable/housing routing
2-bolt drive unit mount
12×148 rear axle spacing
Integrated YAMAHA speed sensor harness
FORK
ROCKSHOX REVELATION RC
160mm TRAVEL
35mm Stanchion eMTB rated Motion Control damping with low-speed compression adjustment Debon
Air air spring
REAR SHOCK
ROCKSHOX DELUXE SELECT +
150mm travel
210X55mm DebonAir+ air spring with 15 clicks of rebound adjustment
2-position compression adjustment
HEADSET
Integrated 1 1/8″
STEM
Alloy 4-both faceplate
35.0 diameter
40mm length
HANDLEBAR
Alloy
35.0 diameter
780mm width
30mm rise
GRIPS
VELO Single Ring Locking
SEATPOST/SADDLE CLAMP
TRANS-X 30.9 dia.
TRAVEL (S) 125mm (M) 150mm (L) 170mm
SEATPOST COLLER
Single-bolt 35.0mm
SADDLE
YAMAHA anti-slip finish with hand rail tail
AXLES
MAXLE 15MM X 110MM BOOST THRU AXLE
SHIFTERS
Shimano DEORE SL-M6100-R
DERAILLEURS
Front: N/A
Rear: SHIMANO DEORE RD-M6100-SGS
CRANKARM
PRAXIS E-CRANK ARM
165mm LENGTH
CHAIN
KMC eTURBO EPT 122 links
CASSETTE
Shimano SLX CS-M7100-12
12-spd
(10-51T)
CHAINRINGS
PRAXIS 36T
BRAKeS/ROTORS
RIMS
YAMAHA 27.5+ Alloy
Tubeless tape installed
Width: 46mm (outside) 40mm (inside)
SPOKES
14g alloy SUS304
HUBS
Anodized Alloy
Centerlock brake mount
15x110mm BOOST+ (front)
12x148mm MicroSpline freehub Quick Release Thru Axle Type
TIRES/TUBE
MAXXIS 27.5X2.6
(F) MINION DHF (R) REKON
ACCESSORIES
Protective motor and battery covers
ISCG05 chainguuide
Safety bell VP Acrylic pedals
(No Keys)
