YAMAHA YDX-MORO 07 SPECIAL EDITION E-Bike

Yamaha 500Wh with Charge-life indicator and Self-diagnosis display
Anti-Vibration Mounting Plate
Weight: 6.61 lbs
500Wh 36V
Re-charge time: 1-hour 80%, 4-hour 100%

51.3lb (M)

YAMAHA PW-X3 Class 1 Labeled
Centermount
ISIS Splined Crankarm Spindle
YAMAHA Quad Sensor with Automatic Support and Walk Assist Modes
Rate power: 250W (nominal), 500W (maximum)
Max torque: 85Nm
Max speed support: 20MPH
Support Modes: ECO, Standard, High, MTB, Extra-Power, Automatic, Walk Assist

YAMAHA Interface X  Control functions include: 3-color LED support-mode level light indicator, (5) Support-mode control switch, plus AUTOMATIC support mode (Aqua LED indicator) and Walk Assist mode (Purple LED indicator), Bluetooth™ connectivity, 3-color LED support-mode level light indicator, LED brightness adjustability, battery capacity (4-LED capacity indicators)

YAMAHA Dual Twin FrameTapered HeadtubeInternal cable/housing routing2-bolt drive unit mount12x148 rear axle spacingIntegrated YAMAHA speed sensor harness

ROCKSHOX LYRIK SELECT
160mm TRAVEL
35mm Stanchions
Charger RC damper with Low-speed Compression and Reboundadjust
Compatible with RockShox premium short fender
Upgradeable to new Pressure Relief Values via RockShox

ROCKSHOX SUPER DELUXE SELECT +
Custom tuned for YAMAHA YDX-MORO 07
150mm travel
210X55mm DebonAir+ air spring with 15 clicks of rebound adjustment, 2-position compression adjustment

Integrated tapered 1 1/8” –  1 1/2” (30mm of spacers)

Alloy 4-both faceplate
35.0 diameter
40mm length

Alloy
35.0 diameter
780mm width
30mm rise

VELO Single Ring Lock

TRANS-X dropper post 30.9 dia.
TRAVEL (S) 125mm (M) 150mm (L) 170m

Single-bolt 35.0mm

YAMAHA anti-slip finish with hand rail tail

MAXLE 15MM X 110MM BOOST THRU AXLE

Shimano XT SL-M8100-R

Front: N/A
Rear: SHIMANO XT RD M-8100-SGS

PRAXIS E-CRANK ARM 165mm LENGTH

KMC eTURBO EPT 122 links

Shimano XT CS-M8100-12
12-spd (10-51T)

PRAXIS 36T

MAGURA MT5 4-PISTON F/R 203MM CENTERLOCK ROTOR (F/R)Single-Finger lever

YAMAHA 27.5+ Alloy
Tubeless tape installed
Width: 46mm (outside) 40mm (inside)

14g alloy SUS304

Anodized Alloy
Centerlock brake mount
15x110mm BOOST+ (front)
12x148mm MicroSpline freehub
Quick Release Thru Axle Type

MAXXIS 27.5X2.6
(F) MINION DHF (R) REKON

Protective motor and battery covers
ISCG05 chainguuide Safety bell
VP Acrylic pedals
(No Keys)
