Yamaha 500Wh with Charge-life indicator and Self-diagnosis display
Multilocation with anti-vibration mounting plate
Weight 6.61lb
500Wh 36V
4-hour charge time

53.1lb (Medium)

PW-X2Center mount
ISIS splined spindle
Quad Sensor System with integrated speed sensor as part of rear hub
Weight: 6.83lb
Rated power: 250W (Nominal), 500W (Max)
Max torque: 80Nm
Max cadence support: 170rpm
Max speed support: 20mph
Support modes: ECO, STD, HIGH, EXPW, AUTOMATIC (ECO-STD-HIGH)
Protective motor cover included

Computer control functions include: (5) Power-level control switch, plus AUTOMATIC support mode, control switch, stop watch, distance units, power-level LED on/off, Bluetooth™ connectivity, USB power, USB connectivity, cycling function display items, time adjustment, 3-color LED power assist level light indicator and push assist button

Cycling function display include: speed, average speed, maximum speed, trip distance, odometer, cadence, battery capacity (%)

Yamaha Dual Twin Frame
Tapered headtube
Internal cable/housing routing
2-bolt motor mount
12 x 148 rear spacing
Integrated speed sensor harness

RockShox YARI RC Boost 160mm
Tapered aluminum steerer, 1 1/8in – 1 1/2in

RockShox Super Deluxe Select +
210mm/55mm
150mm travel

Integrated tapered headset with headset spacers

Yamaha Alloy 4-bolt faceplate
35.0 diameter
40mm length

Alloy 30mm riser bar
35.0mm diameter
780mm width

Locking Dual Core

Alloy 30.9mm dropper post (S/M) 125mm travel, (L) 150mm travel

Single-bolt 35.0mm

Yamaha Anti-slip finish with hand rail tail

Shimano XT
11-speed

Front: N/A
Rear: SHIMANO XT Long-Cage

PRAXIS ISIS
170mm

KMC e11 Turbo EPT

Shimano XT
11-speed
11/46T)

Praxis Wave 36T 104 BCD

Yamaha 27.5+ Alloy
Tubeless tape installed
Width: 46mm (OUTSIDE) 40mm (INSIDE)

Spokes SUS304

Anodized
Centerlock brake mount
15X110 Boost, rear hub 12 x 148 Hyperglide freehub and Yamaha Bicycles Speed Sensor

Maxxis High Roller II 27.5 x 2.8in
Tubeless compatible rim
Tubeless compatible rim strip

Bell(No keys)
